Electrolux IC44819FFS - Page 41

4511 20
7
Notice
Date Page
05102004
INSTALLATION
MANUAL
Note : G20 (H) = naturel gas, Lacq type (20 mbar)
G25 (L) = naturel gas, Groningue type (20 or 25 mbar)
G30 (H) = butane gas (28/30, 50 mbar)
G31 = propane gas (28/30, 37, 50 mbar)
7. Installation
TABLE OF CORRESPONDENCES - Ironer 1.9 m
Categorie
index
Type of
gas
Working supply
pressure in mbar
Hi
Ø of
injectors
in mm
Pressure at
injectors in
mm H
2
O
Heat
emission
Qn in kW
(Hi)
Consumption
Mn in kg/h
Consumption
Vn in m³/h
*2E, 2H,
2ESI
G 20 20 34.02 MJ/m³ 3.30 97 39 - 4.13
2L, 2ESI G25 25 29.25 MJ/m³ 3.30 133 39 - 4.80
3 + G30
G31
28-30
37
45.65 MJ/kg
46.34 MJ/kg
1.85
1.85
-
-
39
39
3.07
3.03
-
-
3 P G31 50 46.34 MJ/kg 1.70 - 39 3.03 -
* For Belgium, no work is allowed between G20 and G25.
TABLE OF CORRESPONDENCES - Ironer 2.5 m
Categorie
index
Type of
gas
Working supply
pressure in mbar
Hi
Ø of
injectors
in mm
Pressure at
injectors in
mm H
2
O
Heat
emission
Qn in kW
(Hi)
Consumption
Mn in kg/h
Consumption
Vn in m³/h
*2E, 2H,
2ESI
G 20 20 34.02 MJ/m³ 3.70 100 52 - 5.50
2L, 2ESI G25 25 29.25 MJ/m³ 3.70 135 52 - 6.40
3 + G30
G31
28-30
37
45.65 MJ/kg
46.34 MJ/kg
2.10
2.10
-
-
52
52
4.10
4.04
-
-
3 P G31 50 46.34 MJ/kg 2.00 - 52 4.04 -
* For Belgium, no work is allowed between G20 and G25.
