05102004
INSTALLATION
MANUAL
Note : G20 (H) = naturel gas, Lacq type (20 mbar)
G25 (L) = naturel gas, Groningue type (20 or 25 mbar)
G30 (H) = butane gas (28/30, 50 mbar)
G31 = propane gas (28/30, 37, 50 mbar)
IMPORTANT
Tightness test after installation
The gas leak test is performed as follows :
1/ Paint pipe joints, pilot gas tubing connections and inspect outlets
with rich soap and water solution; do not use an aggressive soap.
2/ Put the machine into service. Bubbles indicate a gas leak.
3/ Eliminate this leak.
Check-out
Before leaving, put the appliance into operation and allow to run a
complete cycle. Watch to ensure that all burner system components
function correctly.
7. Installation
TABLE OF CORRESPONDENCES - Ironer 3.2 m
Categorie
index
Type of
gas
Working supply
pressure in mbar
Hi
Ø of
injectors
in mm
Pressure at
injectors in
mm H
2
O
Heat
emission
Qn in kW
(Hi)
Consumption
Mn in kg/h
Consumption
Vn in m³/h
*2E, 2H,
2ESI
G 20 20 34.02 MJ/m³ 4.00 114 65 - 6.87
2L, 2ESI G25 25 29.25 MJ/m³ 4.00 160 65 - 7.99
3 + G30
G31
28-30
37
45.65 MJ/kg
46.34 MJ/kg
2.30
2.30
-
-
65
65
5.12
5.05
-
-
3 P G31 50 46.34 MJ/kg 2.10 - 65 5.05 -
* For Belgium, no work is allowed between G20 and G25.
