Electrolux „KITE“ Bar graph Variant - KITE 7 Segment Variant

- 6 -
DGS-TDS-N 12.07 U. H. / A. B. © Electrolux 599 531 461 EN
6 2 7 8 7 2
1 2 7 3 4 5 7 2
Sample Illustration
2.2.2 „KITE“ 7 Segment Variant
1 Locking/child safety lock with display
2 Additional multizone or additional connection of special functions with LED, depending on
appliance class/make
3 Cooking stage selection
4 Cooking zone displays (LED) timer function
5 Timer display, 2x 7 segment displays
6 On/Off with display
7 Cooking zones status displays (LED) depending on appliance class/make
8 Timer operation
