Page #17 background image
INSTALLATION INSTRUCTIONS | SMART LINE BOILING PAN
EN | 10-2018 DOC N° ST0 9183-02 17
SPECIFICATIONS
11. TECHNICAL SPECIFICATIONS
(SM6B) Smart
Boiling pan without agitator
(SM6V) Smart Variomix
Boiling pan with Variomix agitator
(SM6P) Smart Promix®
Boiling pan with Promix® agitator
(SV6I) Smart Variomix ICE
Boiling pan with Variomix agitator and option ice
water cooling
(SP6I) Smart Promix® ICE
Boiling pan with Promix® agitator and option ice
water cooling
11.1 Electrically heated boiling pans, 400V 3N~50Hz*
PNC Model Volume
L
Heating
kW
Tilting
motor
kW
Agitator
motor
kW
Total
power
kW
Max.
Phase
current
A
Rec.
fuse
A
Max.
fuse
A
232218 SM6B50 50 15.0 0.19 - 15.0 22 25 50
232223 SM6V50 50 15.0 0.19 0.75 15.8 27 32 50
232149 SM6V80 80 22.5 0.19 0.75 23.3 38 40 50
232219 SM6B100 100 22.5 0.19 - 22.5 33 35 50
232224 SM6V100 100 22.5 0.19 1.5 24.0 39 40 50
232228 SM6P100 100 22.5 0.19 2.2 24.7 39 40 50
232220 SM6B150 150 30.0 0.37 - 30.0 44 50 63
232225 SM6V150 150 30.0 0.37 1.5 31.5 50 50 63
232229 SM6P150 150 30.0 0.37 2.2 32.2 50 50 63
232221 SM6B200 200 37.5 0.37 - 37.5 55 63 100
232226 SM6V200 200 37.5 0.37 2.2 39.7 62 63 100
232230 SM6P200 200 37.5 0.37 3.0 40.5 66 80 100
232222 SM6B300 300 50.0 0.37 - 50.0 73 80 100
232227 SM6V300 300 50.0 0.37 2.2 52.2 80 80 100
232231 SM6P300 300 50.0 0.37 3.0 53.0 84 100 100
* The connection lead may be at most 32 mm² to have room in the connection terminals.
11.2 Electrically heated boiling pans, 400V 3N~50Hz*, with optional dual
electrical connection
PNC Model
Volume
L
Heating
kW
Tilting
motor
kW
Agitator
motor
kW
Total
power
kW
Max.
Phase
current
A
Rec.
fuse
A
Max.
fuse
A
Q1 Q2 Q1 Q2 Q1 Q2 Q1 Q2
232222 + 928159 SM6B300 300 50.0 0.37 - 25 25 36 36 40 40 63 63
232226 + 928160 SM6V200 200 37.5 0.37 2.2 25 25 36 25 40 32 63 63
232227 + 928160 SM6V300 300 50.0 0.37 2.2 25 27.2 36 43 40 50 63 63
232230 + 928160 SM6P200 200 37.5 0.37 3.0 25 15.5 36 29 40 32 63 63
232231 + 928160 SM6P300 300 50.0 0.37 3.0 25 28 36 47 40 50 63 63
* The connection lead may be at most 32 mm² to have room in the connection terminals.
11.3 Steam heated boiling pans, 230V 1N~50Hz*
PNC Model Volume
L
Heating
kg/h
Tilting
motor
kW
Agitator
motor
kW
Total
power
kW
Max.
Phase
current
A
Rec.
fuse
A
Max.
fuse
A
232232 SM6B50S 50 24 0.19 - 0.2 2 10 16
232233 SM6B100S 100 36 0.19 - 0.2 2 10 16
* The connection lead may be at most 6 mm² to have room in the connection terminals.
