Electrolux Smart Variomix Installation Instructions

INSTALLATION INSTRUCTIONS | SMART LINE BOILING PAN
18 DOC N° ST0 9183-02 EN | 10-2018
11.4 Steam heated boiling pans, 400V 3N~50Hz*
PNC Model Volume
L
Heating
kg/h
Tilting
motor
kW
Agitator
motor
kW
Total
power
kW
Max.
Phase
current
A
Rec.
fuse
A
Max.
fuse
A
232237 SM6V50S 50 24 0.19 0.75 1.0 7 10 16
232238 SM6V100S 100 36 0.19 1.5 1.7 9 16 20
232242 SM6P100S 100 36 0.19 2.2 2.4 9 16 20
232234 SM6B150S 150 47 0.37 - 0.5 3 10 16
232239 SM6V150S 150 47 0.37 1.5 2.0 9 16 20
232243 SM6P150S 150 47 0.37 2.2 2.8 9 16 20
232235 SM6B200S 200 59 0.37 - 0.5 3 10 16
232240 SM6V200S 200 59 0.37 2.2 2.8 10 16 20
232244 SM6P200S 200 59 0.37 3.0 3.6 14 16 20
232236 SM6B300S 300 78 0.37 - 0.5 3 10 16
232241 SM6V300S 300 78 0.37 2.2 2.8 10 16 20
232245 SM6P300S 300 78 0.37 3.0 3.6 14 16 20
* The connection lead may be at most 6 mm² to have room in the connection terminals.
11.5 Electrically heated boiling pans 400V 3N~50Hz* and option ice water
cooling
PNC Model Volume
L
Heating
kW
Tilting
motor
kW
Agitator
motor
kW
Drainwater
pump
A
Total
power
kW
Max.
Phase
current
A
Rec.
fuse
A
Max.
fuse
A
232223 + 928153 SV6I50 50 15.0 0.19 0.75 0.51 15.8 27 32 50
232149 + 928164 SV6I80 80 22.5 0.19 0.75 0.51 23.3 38 40 50
232224 + 928154 SV6I100 100 22.5 0.19 1.5 0.51 24.0 39 40 50
232228 + 928154 SP6I100 100 22.5 0.19 2.2 0.51 24.7 39 40 50
232225 + 928155 SV6I150 150 30.0 0.37 1.5 0.51 31.5 50 50 63
232229 + 928155 SP6I150 150 30.0 0.37 2.2 0.51 32.2 50 50 63
232226 + 928156 SV6I200 200 37.5 0.37 2.2 0.51 39.0 62 63 100
232230 + 928156 SP6I200 200 37.5 0.37 3.0 0.51 40.5 66 80 100
232227 + 928157 SV6I300 300 50.0 0.37 2.2 0.51 52.2 80 80 100
232231 + 928157 SP6I300 300 50.0 0.37 3.0 0.51 53.0 84 100 100
* The connection lead may be at most 32 mm² to have room in the connection terminals.
11.6 Steam heated boiling pans 400V 3N~50Hz* and option ice water cooling on request
Model Volume
L
Heating
kg/h
Tilting
motor
kW
Agitator
motor
kW
Drainwater
pump
A
Total power
kW
Max. Phase
current
A
Rec. fuse
A
Max. fuse
A
SV6I50S 50 24 0.19 0.75 0.51 1.0 7 10 16
SV6I100S 100 36 0.19 1.5 0.51 1.7 9 16 20
SP6I100S 100 36 0.19 2.2 0.51 2.4 9 16 20
SV6I150S 150 47 0.37 1.5 0.51 2.0 9 16 20
SP6I150S 150 47 0.37 2.2 0.51 2.8 9 16 20
SV6I200S 200 59 0.37 2.2 0.51 2.8 10 16 20
SP6I200S 200 59 0.37 3.0 0.51 3.6 14 16 20
SV6I300S 300 78 0.37 2.2 0.51 2.8 10 16 20
SP6I300S 300 78 0.37 3.0 0.51 3.6 14 16 20
* The connection lead may be at most 6 mm² to have room in the connection terminals.
