Technical data
10
Technical data, T4650
Heating Electric Steam Gas
Drum volume: 650 litres 650 litres 650 litres
Weight: Net 340 kg 345 kg 325 kg
Drum: Diameter 913 mm 913 mm 913 mm
Depth 998 mm 998 mm 998 mm
Revolutions per minute 44 rpm 44 rpm 44 rpm
G-factor 0.9 0.9 0.9
Load: 35 kg 35 kg 35 kg
Motor: Effect of drum motor 0.37 kW 0.37 kW 0.37 kW
Effect of fan motor 0.80 kW 0.80 kW 0.80 kW
Revolutions per minute:
Motor 50 Hz, drum 1400 rpm 1400 rpm 1400 rpm
Motor 60 Hz, drum 1680 rpm 1680 rpm 1680 rpm
Motor 50 Hz, fan 2800 rpm 2800 rpm 2800 rpm
Motor 60 Hz, fan 3300 rpm 3300 rpm 3300 rpm
Heat effect: Electric heating 30.0 kW Variable, depending
Electric heating 36.0 kW on steam pressure
Gas heating 57.0 kW
Air consumption: Electric 30.0 kW 1500 m
3
/h
Electric 36.0 kW 1500 m
3
/h
Steam 1500 m
3
/h
Gas 1500 m
3
/h
Pipe connection: Evacuation Ø 200 Ø 200 Ø 200
Steam: ISO 7/1-Rp 3/4
Condensate outlet: ISO 7/1-Rp 3/4
Steam: Recommended pressure
(absolute) 100-1000 kPa
Max. allowable pressure 1000 kPa
Drop in pressure: Evacuation max. 340 Pa max. 340 Pa max. 340
Gas pipe connection: ISO 7/1-R3/4
Gas pressure: See page regarding pressure
Noise level: < 70 dB (A) < 70 dB (A) < 70 dB (A)
