Installation
31
Electric installation
To be carried out by qualified personnel
The tumble dryer must be connected to its own fuse group
and multi-pole main switch according to IEC 60947.
The sizes of the fuse group and the effect are shown on the
following page.
The tumble dryer must be equipped with supplementary
protection in accordance with heavy current regulations.
For calculation of the connection cable dimension, please
refer to local guidelines.
Connecting the cable (within the EU and EEA)
1. Demount cover plate A, fig. 1 on the following page.
2. Pass the feeder cable through cable gland
**, fig. 1 on the
following page.
3. Turn knob* to ‘O’/‘OFF’
4. Connect the feeder cable as illustrated on the following
page.
5. Remount cover plate
A .
6. Function check the dryer
The function check is described in the back of this manual.
* Lockable knob is fitted on machines type 4530 and 4650
for countries within the EU and EEA (the machine directive
standard for disconnecting the electrical supply during
servicing).
