Electrolux T4530 Installation Manual

Technical data
7
Dimension sketch T4290, T4530, T4650
Electric and
gas heating
Steam heating
G
L
H
F
H
A
C
B
D
E
J
M
O
P
N
5
6
4
3
3
I
I
K
1
2
7
A B C D E F G H
I J K L M N O P
T4290 710 1120 1880 780 725 1610 470 135
T4530 960 1180 1995 720 650 1725 595 155
T4650 960 1370 1995 720 650 1725 595 155
T4290 170 700 1810 1395 250 500 70 190
T4530 225 950 2120 1510 270 595 140 170
T4650 225 950 2300 1510 270 595 140 170
1 Door opening Ø 580 Ø 810
2 Operating panel
3 Electric connection
4
Gas connection
5
Steam in
6
Steam out
7 Pipe connection, evacuation
T4530/T4650
T4290
