Installation
Transportation and unpacking,
WD4130, WD4240
The machine is delivered complete with expan-
sion bolts etc. packed inside the machine in the
drum.
The machine is delivered bolted onto the
transport pallet and packed in a crate or box.
• Removepackingfromthemachine.
• Removefrontandrearpanel.Removethe
bolts between the machine and pallet.
• Mountfrontandrearpanel.
• Mountthefeet.
• Placethemachineonitsnalposition.
• Levelthemachinewiththefeetofthe
machine.
The machine also comes with transport safety
devices (two plate angles between the support
and the drum).
In order to remove the safety devices:
• Removethetwosidepanels.
• Removethetwotransportsecurities.
• Themachinemaynotbemovedwiththe
transport securities removed. Save the trans-
port securities for future use.
