Electrolux WD4130 - Exhaust Duct Requirements

18
Installation
Exhaustduct
• Theexhaustductmustbesmoothontheinside(lowairresistance).
• Theexhaustductmustleadtotheoutdoors.
• Theexhaustductmustleadclearofthebuildingascondensationmay
cause frost damage to the building.
• Theexhaustductmustbeprotectedagainstrainandforeignobjects.
• Theexhaustductmusthavegentlebends.
• Theexhaustductmustnotbeasharedductbetweenmachineesand
appliances using gas or other fuels as their energy source.
When several machines share an exhaust duct:
• Theexhaustductdiametermustincreaseaftereachmachine.
The table below shows the exhaust duct diameter and the necessary
fresh-air inlet area.
NOTE!
It is recommended that each machine is connected to a separate
exhaust duct.
The evacuation pipe diameter must not be reduced.
