Electrolux WD4130 - Gas Pressure and Conversion WD4240

45
Installation
Table of pressure and adjustment WD4240
This gas appliance has been build to run on natural gas group I2H and I2E,
commonly identified by GNH. (Japan: LPG).
The data label shows the nozzle size and the nozzle pressure and the
countries that use this gas quality: AT,BG,CZ,DK,EE,FI,GR,HR,HU,IS,IE,IT,
LV,LT,NO,PT,RO,SK,SI,ES,SE,CH,TR,GB,andnon-Europeancountries.
Before connecting the appliance please make sure that the supplied gas
type is correct.
Following gas conversions are possible:
• AppliancestobeinstalledtorunonGNHorGNLinFR,BE:I2E+
• AppliancestobeinstalledinNL,partsofDE:I2L,l2LL.
• AppliancestobeinstalledtorunonLPGin:
BE,CH,CY,CZ,ES,FR,GB,GR,IE,IT,LT,LU,LV,PT,SK,SI:l3+
• AppliancestobeinstalledtorunonLPGin:BE,CY,DK,EE,FR,GB,HU,IT,
LT,NL,NO,SE,SI,SK,RO, HR,TR,BG,IS,LU,MT and Non-European
countries: I3B/P (30 mbar) inlet pressure.
• AppliancestobeinstalledtorunonLPGin:PL:I3B/P(50mbar)inlet
pressure.
• AppliancestobeinstalledtorunonLPGin:AT,CH,DE,SK:I3B/P
(37 mbar) inlet pressure.
• AppliancestobeinstalledtorunonLPGin:FI,NL,ROandNon-Europe-
an countries: I3P (30 mbar) inlet pressure.
• AppliancestobeinstalledtorunonLPGin:
BE,CH,CZ,IE,IT,ES,FR,GR,GB,HR, LT,NL,: I3P (37 mbar) inlet pressure.
• AppliancestobeinstalledtorunonLPGin:AT,CH,DE,NL,LU,SK:I3P
(50 mbar) inlet pressure.
Gas group Nozzle size
ø mm (1)
Air reducing
plate
Inlet pres-
sure (mbar)
Nozzle
pressure
(mbar)
Label no.
I2H, I2E 3.60 A+D 20-25 10 DEFAULT
I2E+ 3.10 B+C 20/25 20/25 490375611
I2L, 12LL 3.60 A+D 20-25 15 490375612
I3+ 2.20 D 28-30/37 28-30/37 490375613
I3B/P 2.20 D 30, 37, 50 28 490375614
I3P 2.30 D 30, 37, 50 28 490375615
LPG Japan 2.20 D 28 28 DEFAULT
WD4240 19 kW
