Installation
Conversion instructions WD4240
• Cutthepowertothemachine.
• Dismounttherearcover(A).
• Removethescrewonthesideofthelocking
platex.
• Pulloutthelockingplatex,thisreleasesthe
gaspipe.
• Removethenozzle(1).
• Turnthepipealittleandmountthesupplied
gasnozzle.
• Pushpipewithnewnozzlebackintoits
place.
• Pushlockingplateallthewayinandtighten
thescrew.
7116
6
3
6
6
7
2
4+3
7117
7
