Electrolux WD4130 - Gas Pressure and Conversion WD4130

43
Installation
Table of pressure and adjustment WD4130
This gas appliance has been build to run on natural gas group I2H and I2E,
commonly identified by GNH. (Japan: LPG).
The data label shows the nozzle size and the nozzle pressure and the
countries that use this gas quality: AT,BG,CZ,DK,EE,FI,GR,HR,HU,IS,IE,IT,
LV,LT,NO,PT,RO,SK,SI,ES,SE,CH,TR,GB,andnon-Europeancountries.
Before connecting the appliance please make sure that the supplied gas
type is correct.
Following gas conversions are possible:
• Appliances to be installed to run on GNH or GNL in FR, BE: I2E+
• Appliances to be installed in NL, parts of DE: I2L, l2LL.
• Appliances to be installed to run on LPG in:
BE,CH,CY,CZ,ES,FR,GB,GR,IE,IT,LT,LU,LV,PT,SK,SI:l3+
• Appliances to be installed to run on LPG in: BE,CY,DK,EE,FR,GB,HU,IT,
LT,NL,NO,SE,SI,SK,RO, HR,TR,BG,IS,LU,MT and Non-European
countries: I3B/P (30 mbar) inlet pressure.
• Appliances to be installed to run on LPG in: PL: I3B/P (50 mbar) inlet
pressure.
• Appliances to be installed to run on LPG in: AT,CH,DE,SK: I3B/P
(37 mbar) inlet pressure.
• Appliances to be installed to run on LPG in: FI,NL,RO and Non-Europe
an countries: I3P (30 mbar) inlet pressure.
• Appliances to be installed to run on LPG in:
BE,CH,CZ,IE,IT,ES,FR,GR,GB,HR, LT,NL,: I3P (37 mbar) inlet pressure.
• Appliances to be installed to run on LPG in: AT,CH,DE,NL,LU,SK: I3P
(50 mbar) inlet pressure.
Gas group Nozzle size
ø mm (1)
Air reducing
plate
Inlet pres-
sure (mbar)
Nozzle
pressure
(mbar)
Label no.
I2H, I2E 3.00 NO 20-25 8 DEFAULT
I2E+ 2.30 NO 20/25 20/25 490375601
I2L, 12LL 3.00 NO 20-25 12 490375602
I3+ 1.60 2 x F 28-30/37 28-30/37 490375603
I3B/P 1.60 2 x F 30, 37, 50 28 490375604
I3P 1.70 E 30, 37, 50 28 490375605
LPG Japan 1.60 2 x F 28 28 DEFAULT
WD4130 10 kW
