Installation
5334
2
5333
3AC
3N AC
  
6526
6525
or
or
3AC
3N AC
2
Three-phase connection:
Connect the earth, neutral and phase wires as
shown in example ”3AC” and ”3N AC” in the
figure.
When the installation is completed, check:
• thatthedrumisempty.
• thatthemachineoperatesbyturningonthe
mains switch, starting the machine and using
RAPIDADVANCEtoreachthespincycle(see
operations manual).
