INSTALLATION
MANUAL
4. Handling
SAFETY
It is obligatory that all these
operations are undertaken
by handling specialists.
1/ Lifting with handling straps
Lifting in that case can only be done with
handling straps (minimum capacity 3000
daN) which bear weight of the machine.
Handling
Before any handling, check that the four
transport locks fi tted (B) are still in place and
well-tightened, and so the four casing locks
(A).
To do so, remove the side casings and
check presence of four locks (B) and the
down casings for the four locks (A).
Check also that the load cells are free of the
tub assembly (weighing option).
N.B. : To handle the machine, you must
imperatively reassemble the transport
bridles and disengage the load cells
(proceed in reverse order of "Remove of
the transport locks fi tted").
