2413 11
7
D1443
Notice
Date Page
05201053
INSTALLATION
MANUAL
7. Installation
Air vent connection
The air vent of the drum opens on the top of
the machine. Connect the bent hose to this
opening.
Connect the air vent, to the outside of the
laundry in accordance with tte legislation.
The air vent should resist to 100°C (212°F)
temperature and allow the condenses to
return to the machine.
Air vent
