Notice
Date Page
05201053
INSTALLATION
MANUAL
6.Technical
characteristics
Washer extractor type 1100 barrier
Diagram No. 07100137
*normal cycle : prewash 3 min at 35 °C, drain 2 min, main wash 4 min at 65 °C, drain 2 min, rinse 2 min, extract 2 min, rinse 2 min, extract
2 min, rinse 2 min, extract 10 min (cold water supply at 15 °C).
Heating Electric Steam Thermic fl uid
Characteristics Ø drum ------------------------------------------------ 1050 mm - 41.33" -----------------------
Drum length ------------------------------------------ 1256 mm - 49.45" -----------------------
Opening drum door (LxH) ------------------------ --- 900x490 mm - 35.43x19.3" --------
Opening cage door (LxH) ------------------------- -- 958x698 mm - 37.71x27.49" -------
Drum volume ----------------------------------------- 1083 dm³ - 1083 l -----------------------
Specifi c load 1/10 ----------------------------------- 108,3 kg - 238.87 lb --------------------
(dry linen, ISO 9398-4)
Floor area ------------------------------------------------------- 2,67 m² - 28.73 sq. ft ------------------
Contact surface with fl oor ---------------------------------------------- 0,25 m² - 388.55 sq. in -----------------
Net weight ------------------------------------------------------ 2850 daN - 6285 lb ----------------------
Weight loaded (high level) ---------------------------------------------- 3608 daN - 7956 lb ---------------------
Water consumption, washing, low level 300 l 300 l 300 l
Water consumption, washing, high level 600 l 600 l 515 l
Max dynamic load ------------------------------------------------------ F = 400 daN - 882 lb --------------------
Max transmitted fl oor load --------------------------------------------- 4450 daN - 9814 lb ---------------------
Max pressure transmitted to fl oor ----------------------------------- 178 kPa - 26 psi ------------------------
Frequency of the dynamic force 0,xx Hz 0,xx Hz 0,xx Hz
Spin effi ciency 300 G 300 G 300 G
Max. unbalance 15 kg - 33 lb 15 kg - 33 lb 15 kg - 33 lb
Main switch to connect main cable
Electric cable (section) 4 x 50 mm² 4 x 10 mm² 4 x 10 mm²
Stuffi ng box for main cable
Supply voltage ------------------------------------------------------ -- 380 / 415 V 3+E ~ 50/60 Hz --------
Installed electric power 91 kW 19 kW 19 kW
Installed heating power 72 kW - -
Electric consumption for a normal cycle* 25,3 kWh/h 2,4 kWh/h 2,4 kWh/h
Heat loss ------------------------------------------------------ -- 3 % of installed heating power -----
Steam inlet Standard : DN 25 (1" BSP) Low pressure : DN 32 (1"¼ BSP)
- Maximum supply pressure 600 kPa - 87 psi 600 kPa - 87 psi
- Steam instaneous fl ow rate at 600 kPa 240 kg/h 240 kg/h
- Steam consumption for a normal cycle* 36 kg/h at 600 kPa 39 kg/h at 50 kPa
Hot water connection / fl ow (T max 60°C)--------------- DN 32 (1"¼ BSP) - 200 l/min at 250 kPa (37 psi)
Cold hard water connection / fl ow ------------------------ DN 32 (1"¼ BSP) - 200 l/min at 250 kPa (37 psi)
Cold soft water connection / fl ow (option) -------------- DN 32 (1"¼ BSP) - 200 l/min at 250 kPa (37 psi)
Water supply minimum pressure ------------------------------------ 50 kPa - 7.25 psi ------------------------
Water supply maximum pressure ----------------------------------- - 600 kPa - 87 psi ------------------------
Water consumption or a normal cycle* ---------------------------- --------------- 1490 l ------------------------
1st/3rd drain connection (pH transmitter option) ------------------ Ø 110 mm - 4.33" -----------------------
2nd drain connection (option) ------------------------------------------ Ø 110 mm - 4.33" -----------------------
Maximum drain fl ow rate ----------------------------------------------- ----------- 380 l/min -----------------------
Waste water collector ---------------------------------------------------- DN 200 mm - 8" BSP ------------------
(3 cm/m (3 %) minimum slope)
Air vent hole ------------------------------------------------------- Ø 80 mm - 3.15" ------------------------
Thermic fl uid inlet DN 20 - 3/4" BSP
Thermic fl uid return DN 20 - 3/4" BSP
- Maximum supply pressure 400 kPa
- Installed calorifi c power xxx kcal
- Average calorifi c consumption xxx kcal/h
- Inner volume thermic fl uid exchanger 10 l
Barrier partition (provided by customer)
Frame 60x100 mm - 2x4" maximum (provided by customer)
Aseptis seal
Compressed air inlet ---------------------------------------------------- Ø 6/8 mm - 1/4" ------------------------
- Min./max. compress air pressure ------------- 5,5/7 bar - 80/100 psi ------------------
- Consumption --------------------------------------- ---------------- 50 l/h -----------------------
Liquid detergents connection ----------------------------------------- Ø 25 mm - 0.99" ------------------------
