A4 TECHNICAL DATA
Standard cycle time may vary should the inlet water temperature be different from that indicated above.
MODEL WT830EAG / PW1EAG WT850EAG / PW2EAG
Supply voltage: V 400...415- 3N~ 400...415- 3N~
Frequency Hz 50 o 60 50 o 60
Max. power input kW 13,5 / 20,5 (*) 15,5 / 26 (*)
Boiler heating elements kW 10,5 10,5
Tank heating elements kW 7 10,5
Water supply press. kPa [bar] 50...700 [0,5...7] 50...700 [0,5...7]
Water supply temp. °C 50 50
Water supply hardness °fH [°dH] 14 [8] max 14 [8] max
Rinse cycle water consumption l 6,2 7,7
Boiler capacity l 16 16
Tank capacity l 95 110
Standard cycle time with water supply at 50°C sec. 180-360-540 180-360-540
Legal noise level Leq dB(A) <70 <70
Protection ratinge IPX4 IPX4
Net weight kg 200 310
Power supply cable H07RN-F H07RN-F
(*) = If activated by software, coincidence of tank and boiler heating elements.
Table 1
400...415V 3N
CS
13.5 kW 5X4 25A 3P+N
20,5 kW 5X6 40A 3P+N
15,5 kW 5X6 40A 3P+N
26 kW 5X10 50A 3P+N
C = Power supply cable
S = On/Off switch
Table 2
