Elegiant 96 - Input Terminals

Input Terminals
10
Signal Terminals Description
Conponent video input
AV input
Audio output
Audio input
VGA input
Analog TV input ( optional )
HDMI Signal input
2*Multimedia Inputs
Pr,Y,Pb,
Video
L out, R out
L in, R in
PC-RGB IN
TV
HDMI 1, HDMI 2
1, 2
Name Description
Caution:
Turn off the power of the projector before connecting the
terminals. Connect the plugs with the correct ports, failure
to do may cause the machine to breakdown.
