Introductions

Projector Description

The projector is able to connect signals: HDMI, Y/Pb/Pr, VGA and

TV(optional), as well as stereo audio input. Please connect in reference to

the following diagrams.

1. Focus lens

2. Hight-feet adjustment

3. Cool air ventilation opening (in)

4. IR receiver

5. Input terminals

6. Power switch

7. Keystone adjustment

8. Input terminals

Back

Front

1 32

4 5 6 7 8

P C- RG B I N

HD M I 1

H D MI 2
