32 / 137
Component Required:
(1) x Elego Uno R3
(1) x USB cable
(1) x Shock switch module
(1) x Mercury switch module
(1) x tilt switch module
(1) x Knock switch module
(x) x F-M wires
Principle
switch and number 13 port have the built-in LED simple circuit. To produce a SWITCH flasher,
we can use connect the digital port 13 to the built-in LED and connect the SWITCH S port to
number 3 port of Elego Uno board. When the SWITCH sensing, LED twinkle light to the SWITCH
signal.
Connection
Schematic
