- 32 -
9.0 Connection of AIRPULLER
– Connect AIRPULLER to central socket (63).
– The unit will switch automatically to the AIRPULLER symbol.
– Select “tool AIRPULLER” with keys AB (uncoded AIRPULLER
only).
– In “planishing” mode select sheet thickness (up to a max. of
2 x 1 mm) with keys EF.
– In “annealing” mode select “anneal” symbol with keys CD.
– Fine-adjust with keys GH, if necessary.
Operating the AIRPULLER please see operating instructions
AIRPULLER.
10.0 Practical hints
When push spot welding pull metal
sheet
When push spot welding properly
press on copper shoe of grounding
cable from below.
When push spot welding firmly press on
metal sheet with screw driver
