Element E850PD - Product Description; Component Views

5
Description
Front View
Right View
1
2
3
5
4
3
6
1
6
7
1.LCD
2.OPE N
7
2
8
4
8
9
5.LCD on/off switch
6.CURSOR(UP/DOWN/LEFT/ RIGHT),
3 .DISC COVER
4.PLAY BACK BUTTONS
PLAY ( )
SKI P - PREVIO US/ FAST
REVERS E( / ) S KIP-
FO RWAR D/ F A ST FO RWA RD( / )
PAUSE /STEP( / )
STOP ( )
ENTER( )
7.MENU/PBC/LCD adj.
8.DVD/USB Button
1.OPEN
2.EARPHONE / SPEAKE R VOLUME
3.DC IN 12V
4.POWER ON/OFF
5.VIDEO IN
6. AUDIO IN/ OU T
7. V IDEO OU T
8. SP D IF: Digit a l aud io signal
ou tput ja c k
9. EARPHONE JACK
Left View Bottom View
1
2
1
2
1.LED LIGHT/REMOTE
CONTROL SE NSOR
2.U S B S lo t
3
1.RELE ASE LATC H (Battery
pack separa tio n switch)
2.B ATTERY PACK
3.SPEAKER
