Element P220 User Manual

P220 Stationary Barcode Scanner User Manual 20
2.2.3 USB Virtual Serial Port
When the scanner uses a USB communication interface, but the host application uses serial
communication to receive data, you can setup the scanner to a USB virtual serial port. This feature
requires that the appropriate driver be installed on the host.
USB Virtual Serial Port Setting
2.3 VID & PID Table
USB uses 2 numbers to identify the device and find the correct device. The first number is VID
(supplier ID), designated by USB Implementers Forum. VID is 1EAB (Hex). The second number is PID
(Device ID), and each interface type assigns a PID number.
Device Name
Interface Type
PID（Hex）
PID（Decimal）
P220
USB virtual serial interface
1f3a
1009
USB virtual keyboard
1f3a
100b

Element P220 Specifications

General

Brand	Element
Model	P220
Category	Barcode Reader
Language	English
