Element PLX-4202B User Manual

- 14 -
Plasma TV Service Manual
Element Confidential
3. PDP panel module
3.1 General Specifications
Model Name PDP42X4#### (42X4
Model)
PDP50X4#### (50X4
Model)
Comments
Number of Pixels
1024(H) × 768(V) 1366(H) × 768(V) 1 pixel=3 RGB cells
Pixel Pitch
900㎛ (H) × 676㎛ (V) 810㎛ (H) × 810㎛ (V)
Cell Pitch
300㎛ (H) × 676㎛ (V) 270㎛ (H) × 810㎛ (V) Green Cell basis
Display Area
921.5(H) × 519.0(V) ±
0.5mm
1106.5(H) × 622.1(V) ±
0.5mm
Outline
Dimension
1005(H) × 597(V) ×
60.7(D)±1mm
1190(H) × 700(V) ×
58(D) ± 1mm
Pixel Type
RGB Closed type RGB Closed(Well) type
Number of
Gradations
(R)1024 × (G)1024 ×
(B)1024
(R)1,024 × (G)1,024 ×
(B)1,024 colors
Aspect Ratio
16:9 16:9
Peak Brightness
Typical 1,500cd/㎡ Typical 1500cd/㎡ 1/100 White Window
pattern at center)
Typical 180:1 Average130:1 (In a bright room with
100Lux at center)
Contrast Ratio
Typical 10,000:1 Maximum 10,000:1 In a dark room 1/100
White Window pattern
at center)
Weight
14.2 Kg ± 0.5 Kg 20.4±0.5 Kg Net 1EA
Power
Consumption
Max.330W Max. 400 W Full White
Expected
Life-time
60,000 Hours 60,000 Hours
Income inspections please refer to panel specification of LGE 42X4and 50X4.
