Plasma TV Service Manual
2.2 Specifications
Model
,
User Manual Warranty Card ,
Diagonal display size
Television system
Channel coverage
Power source
Power consumption
Audio power
Conection Interface
Dimensions
Weight
Supplied accessories
American TV standard ATSC /NTSC system
VHF: 2~13 UHF: 14 69 CATV:1~~125
~6
~1
Digital Terrestrial Broadcast (8VSB): 2 9
Digital cable (64/256 QAM): 1 35
AC 120 V , 60 Hz
350W
Remote control, AC cord, Batteries
RF input: Cable/ Antenna 1×
VIDEO input: VIDEO 2×
S-VIDEO 2×
COMPONENT 2×
GRAPHIC input: Analog RGB 15pin 1×
AUDIO
input: AV Audio 2×
Component Audio 2
PC Audio Input 1
×
×
42 inches
10W+10W
80.3 lbs
VIDEO output: VIDEO 1
×
AUDIO output: AV Audio 1
Digital audio output 1
×
×
Length: 41.4 inches
Width: 14.2 inches
Height: 30.2inches
PC mode
YPbPr/YCbCr mode
640 480/60Hz,800 600/60Hz,1024 768/60Hz×× ×
480I/60Hz,480P/60Hz,720P/60Hz,1080I/60Hz
Resolution 1024 768×
HDMI 2×
Audio multiplex
BTSC system
PLX-4202B
PLX-5002B
50 inches
1366 768×
500W
Length: 49 inches
Width: 14.2 inches
Height: 36.3inches
109.5 lbs
Stand Assemble Guide, QSG, Remote Control Guide
NOTE: Specifications and design are subject to possible modifications without notice due to
improvements。
