5. Factory/Service OSD Menu and Adjustment
5.1 To enter the Factory OSD Menu
a. With factory RC (remote control)
1. Press “M” button and enter factory mode.
2. Press “Menu” button and enter factory OSD menu.
3. Press “CH+”/“CH-” button select the function menu, press “VOL+”/“VOL-” enter the selected
function menu. Press “VOL+”/“VOL-” button adjust values in the menu.
b. With user’s RC
1. Power TV On
2. Press Menu button and call up User OSD Menu
3. Select Audio-> Balance
4. Enter 0->5->3 ->2 in sequence.
Note: If necessary, re-do number keys.
5. Factory OSD appears.
6. Press Menu again and leave the factory OSD.
5.2 Factory OSD Menu
5.2.1 White Balance
Note: Different source has different WB values. Before adjusting, please change to desired source.
Auto Color
Item Default Options Notes
1 ADC VGA For VGA source
2 ADC HDTV For Component Video
5.2.2 Factory Option
Item Default Options Notes
1 MODE M M, U
M-Can enter factory mode
with factory RC or user RC.
U-Can enter factory mode
only with user’s RC.
Note: MODE “M” is only used for factory production.
