Element PLX-5002B - Page 24

- 24 -
Plasma TV Service Manual
Element Confidential
Cool：
TV AV S-Video Component VGA HDMI
R Gain -3 -3 -3 -4 -2 -3
G Gain 0 0 0 0 -2 0
B Gain 0 0 0 0 -1 -1
Warm：
TV AV S-Video Component VGA HDMI
R Gain 14 14 14 11 9 14
G Gain 12 12 12 7 6 9
B Gain -12 -12 -12 -17 -19 -17
5.3.2 Video Curve:
TV AV S-Video Component VGA HDMI
Bright Max 620 620 620 700 660 670
Bright Min 0 0 0 0 0 0
Bright Mid 480 480 480 540 530 540
Contrast Max 600 600 600 570 570 570
Contrast Min 0 0 0 0 0 0
Contrast Mid 500 500 500 470 470 470
Saturation Max 600 600 600 600 600 600
Saturation Min 0 0 0 0 0 0
Saturation Mid 500 500 500 500 500 500
Hue Max 1000 1000 1000 1000 1000 1000
Hue Min 0 0 0 0 0 0
Hue Mid 474 474 474 474 474 474
5.3.3 Picture Mode
TV AV S-Video Component VGA HDMI
Vivid Bright 65 65 65 65 60 65
Vivid Contrast 65 65 65 65 60 65
Vivid
Saturation
65 65 65 65 60 65
Std Bright 50 50 50 50 50 50
Std Contrast 50 50 50 50 50 50
Std Saturation 50 50 50 50 50 50
