INSTALLER INFORMATION
Log Arrangements - Sirius
Only the ceramics supplied with this appliance are to be used. The ceramics must be laid only as
shown on this page. Replacement parts are available from your dealer, but should only be installed by
a qualied installation engineer.
Ensure that the grate is sitting rmly in the base of the re box, with the long slot in the centre of the
Grate aligning with the centre slots on the Burner Tube. The Pilot ame must be visible through the
grate and the cut-out in the Pilot Shield. First place the two coals against the backwall. Make sure there
is a gap between the center back log and the back wall of the re.
Ensure that a number of holes in the Grate and the Pilot area are free of embers.
After placing the embers and logs according to the gures sprinkle some ashes over the logs
and embers.
Finally check the pilot is clear, no embers have entered the Pilot area and the cross lighting is good
before the glass is replaced.
This appliance does have a second thermocouple.
Also this area must be clear of any ceramic materials.
Make sure that second thermocouple is nicely in ames.
