Elements eONE - Rear Connections

11
elements
enabling technologies for Life Science
eONE - User’s guide
Figure 3
Rear Connections
2.4.2 Rear Connections
USB
LED
Ground
On the rear of eONE there are two connectors:
- mini-B female USB connector to connect to the PC through the in-
cluded USB cable;
- 2mm gold plated ground female connector to connect the eONE
ground to the Faraday cage;
3
2
1
3
2
1
