34
5.2 Factory settings
The equipment comes with the following default factory settings.
If they correspond to your requirements, just put the machine in RF ON. Should you
need to change the parameters, please refer to paragraph “Main parameter setup”.
ETG EQUIPMENT VERSION
FACTORY
SETTINGS
With Stereo Coder board (it works
in MPX,Stereo,Mono modes)
With Stereo Coder bo-
ard + AES/EBU (it works in
MPX,Stereo,Mono,AES/ EBU
modes)
Output power (TRG) Maximum value Maximum value
Frequency 98.000 MHz 98.000 MHz
L,R input sensitivity for
+/-75 kHz deviation
0dBm 0dBm
MPX input sensitivity
for +/-75 kHz deviation
0dBm 0dBm
AUX input sensitivity 0dBm 0dBm
Stereo subcarrier
19kHz
OFF (MPX input mode) OFF (MPX input mode)
Pre-emphasis 0uS (linear) 0uS (linear)
Clipper OFF OFF
“NO AUDIO” alarm
OFF, set with non-intervention
thresholds (-
25 dB for 600s)
OFF, set with non-intervention
thresholds (-25 dB for 600s)
VSWR/ROS foldback
O
N, threshold protection
O
N, threshold protection
Interlock External cable External cable
Profile ID 1 1
The equipment comes with the programming lever factory-set downwards (running
mode).
Quick instructions for commissioning
