GENERAL DATA
Output Nominal Power (@230V)
(N.B. @ 115V Singlephase the output nomi-
nal power remains constant except for ETG
1600.3 and ETG 1200.2 where a derating of
the maximum output power may occur)
1600W adjustable (ETG 1600.3)
1200W adjustable (ETG 1200.2)
800W adjustable (ETG 800.1)
150W adjustable (ETG 150)
30W adjustable (ETG 30)
Automatic power RF control Stabilizes the output power value on the set value
Overall output power RF stability +/-0,1 dB
Operating band 87.5 - 108 MHz
RS232/RS485 Yes
Points of measure RF Sample - MPX Monitor
Displayed Parameters More than 50 parameters displayed on a wide graphic
OLED
Adjustments From the frontal panel through OLED/from PC
Number of MOSFETs in power amplifi er stage 3 (ETG 1600.3)
2 (ETG 1200.2)
1 (ETG 800.1 - ETG 150)
0 (ETG 30)
RF power stage technology ICEFET & ECOSAVING
Dimensions: Rack units 2U
Dimensions: W - H - D 48.5 - 8.8 - 70 cm
Weight 14.8 Kg
Number of cooling fans in the amplifi ers 3 (ETG 1600.3 - ETG 1200.2)
2 (ETG 800.1 - ETG 150 - ETG 30)
PERFORMANCE AUDIO/STEREO CODER
AES/EBU Input Resolution 24bits
AES/EBU Input Sample Rate 32,44.1,48,96 KHz Automatically selected
AES/EBU-Analog input automatic changeover Yes
L/R Audio input level +15/-10 dBm for 75KHz standard deviation
L/R level adjustment Soft adjust 0.1dBm steps from front panel
L/R Input Impedance Selectable 10K - 600
Ω
MPX audio input level +15/-10 dBm for 75KHz standard deviation
MPX level adjustment Soft adjust 0.1 dBm steps from front panel
MPX Input impedance 5KΩ selectable
SCA/RDS audio input level 0 dBm for 75KHz standard deviation
PILOT Amplitude adjustment Soft adjust 0.05% steps from front panel
PILOT Phase adjustment Soft adjust 0.01 degree steps from front panel
PILOT Tone Frequency 19 KHz
PILOT Tone Deviation 7,5 KHz Adjustable
PILOT Tone Frequency Stability +/-1 Hz
THD+N <0.03% @ 1KHz
Pre-emphasis 0/25/50/75 microseconds +/-0.1dB
FM S/N MPX FCC 82 dB 20Hz - 23KHz - 50uS - ref @ 53KHz - RMS
FM S/N STEREO CCIR Weighted 72 dB Weight-ref@53KHz-Qpk
FM S/N STEREO CCIR Unweighted 72 dB Unweight-ref@53KHz-QPk
Stereo Crosstalk -65 dB or better @ 1KHz
PERFORMANCE EXCITER
PLL lock time <10sec
Intermodulation distortion <0.05% Measured with two of tones 1KHz & 1.3KHz,
ratio 1:1 at 100% modulation
Frequency deviation +/- 75 KHz 0.1 dB steps adjustable
RF Frequency steps 10 KHz
Phase Response 0.1 degree from linear phase; 53kHz to 100kHz
Modulation Capability +/-250 KHz
INSTALLATION REQUIREMENTS
Power supply 110, 230 Two-Singlephase Version 50-60Hz VAC
Power consumption (typical@230V)
(N.B. @ 115V Singlephase the power con-
sumption for ETG 1600.3 and ETG 1200.2 is
50% consumption to 230V)
2.2KW (ETG 1600.3)
1.7KW (ETG 1200.2)
1.15KW (ETG 800.1)
300W (ETG 150)
60W (ETG 30)
Current consumption (typical@230V)
(N.B. @ 115V Singlephase the current con-
sumption remains constant except for ETG
800.1, ETG 150 and ETG 30 where is twice
the consumption @230V)
9.6A(ETG 1600.3)
7.4A(ETG 1200.2)
5A(ETG 800.1)
1.3A(ETG 150)
0.3A(ETG 30)
COOLING SYSTEM
Cooling system Forced air-cooling
ENVIRONMENT
Temperature range (operating) -5 - +45 °C
Temperature range (non operating) -20 - +55 °C
Humidity range (operating) 95% @ 40 °C
Humidity range (non operating) 90% @ 55 °C
Altitude range (operating) <3000 meters
Altitude range (non operating) <15000 meters
TELECONTROL & TELEMETRY
Remote control Yes
Remote Control at clean contacts Yes
SNMP option Yes (external)
