ELGA PC220DIBPM3 - CONNECT THE PURIFIED WATER OUTLET (PORT NO.4); Use Only Supplied COMMS Cable

SET - UP
N.B This product is not suitable to operate directly with a chorus dispenser.
COMMS CONNECTIONS
5
Reservoir J2 or J1
Connect to:
Port 7
or
Port 9
See ‘Reservoir
Installation Guide’.
RESERVOIR NOTE
6
O2
Water needs to be re-directed from
Port 4a: product outlet to drain during
commissioning mode.
CONNECT THE PURIFIED WATER OUTLET (PORT NO.4)
4
a. Remove the transit plugs from the water
outlet connection.
b. Using the tube supplied,  rmly push one end
securely into the water connector.
or
or
c. Turn on the water supply.
Minimum Pressure 0.5bar (7.5psi) with boost pump / 4.0bar (58psi) without boost pump.
Maximum Pressure 2.0bar (30psi) with boost pump / 6.0bar (90psi) without boost pump.
WARNING!
ONLY USE COMMS CABLE SUPPLIED BY ELGA
®.
