11
62 Speed forward hand fast Rpm 1000
63 Speed forward hand slow Rpm 100
64 Direction of manual buttons 0.1 0
65 Speed to fixed position Rpm 500
66 Acceleration for fixed position revs/sec2 5
67 Speed datum sequence phase 1 Rpm 100
68 Speed datum sequence phase 2 Rpm 10
69 Speed datum sequence with
relays phase 1
0,1,2 0
88 System Register 4 See para 7.42 000000
90 Button enable in service mode 0,1,2 0
94 Inch / factor multiplier 0.0to 9.99999 0
96 Encoder pulse multiplication
0.00001 to 9.99999
100000
97 Inch / mm selection 0,1,2,3 0
98 Security code 250565
99 Service - -
*Logical sequence values such as these must always be present, regardless whether
3 speed, 2 speed or 1 speed drive is used.
P1 > P2 > P3 for 3 speed drive P1 = P2 > P3 for 2 speed or 1 speed drive.
Registers R06 and R07 can be accessed and changed without need for the Security Code.
The Registers R50 to 55, 57 to 63 and 65 to 68 are for analogue output only.
