15. Type designation
P = Position Controller
Series
P8511 without program memory
Programme Memory
1 = none
Number of Axes
Construction
000 = standard
001 = 1
st
special version
etc.
Supply voltage
024 = 24 V DC
115 = 115 V AC
230 = 230 V AC
Encoder input
0 = A/B 24V/24V 20KHz PNP
1 = A/B/0 24V24V 20KHz PNP
2 = 5 V line receiver
3 = 5V line receiver with index input
8 = A/B 24V /24 neg. logic NPN
Special Features
P = Analogue closed loop
R = Relay output
EN = input NPN (including marker)
S= Serial communication link RS232
To Next Page
