Elitech RC-5 User Manual

Windows xp, WIN7, and mac. For the details, please refer to Help file of RC-5 data
management software.
14. RC-5 parameter setting items in temperature data logger data management
software：
Note: It is the factory default setting in the brackets. The factory
default state of data logger is without starting.
record interval (15 min); start delay time (0); meter station (1); Button
stop (Disabled); temperature unit (° C); upper temperature limit (60 °
C); lower temperature limit (-30 ° C); temperature calibration (0 ° C);
clock set (current time); set the number (001); set user information
(RC-5).
VIII.Battery replacement：
：：
：
Figure 9 Figure 10 Figure 11 Figure 12
Figure 13 Figure 14 Figure 15 Figure 16
Replacement steps：
：：
：
1.Rotate the battery cover clockwise to the position as shown in Figure 10.
2. Remove the battery cover.
3. Remove the old battery from the battery slot.
4. Put the new battery into the battery slot.
5. Place the battery cover in the position shown in Figure 14.
6. Rotate the battery cover counter clockwise to the position shown in Figure 16
Note: The pole piece in the bottom of the battery slot is negative.
IX.Accessory list
Standard accessory list
One RC-5 temperature data logger
One software installation CD
One operation instruction

Elitech RC-5 Specifications

General

Brand	Elitech
Model	RC-5
Category	Data Loggers
Language	English
