EWPlus + ECPlus
5/8
TECHNICAL DATA (EN 60730-2-9)
Classification: control device (not safety) to integrate
Mounting: panel mounting with 71x29 mm (+0.2/-0.1 mm) drilling template
Control type: 1.B
Pollution rating: 2
Material class: IIIa
Overvoltage category class: II
Nominal impulsive voltage: 2500V
Temperature: Operating: –5 … +55 °C - Storage: –30 … +85 °C
Power Supply: 230Va (±10%) 50/60 Hz
Consumption: 4.5W max
Digital Output (relays): please refer to the device label
Fire resistance class: D
Software class: A
NOTE: check the power supply specified on the instrument label; for relay, power supply capacities and PTC probes, contact
the Sales Office.
FURTHER INFORMATIONS
Input Characteristics
Display Range: NTC: –50.0°C ... +110°C; PTC: –55.0°C ... +140°C (on display with 3 digit + sign)
Accuracy: Better than 0,5% of full-scale + 1 digit
Resolution: 0,1 °C
Buzzer: YES (it depends from model)
Analogue Input: 1 NTC input (EWPlus 961) or 2 NTC inputs (EWPlus 971/974)
Digital Input: 1 voltage-free digital input (D.I.1)
Output Characteristics
Digital Output: EWPlus 961: 1 Compressor relay: UL60730 2 Hp (12FLA - 72LRA) max 240Va
EWPlus 971: 1 Defrost relay: N.A. 8(4)A - N.C. 6(3)A max 250Va
1 Compressor relay: UL60730 2 Hp (12FLA - 72LRA) max 240Va
EWPlus 974: 1 Defrost relay: N.A. 8(4)A - N.C. 6(3)A max 250Va
1 Compressor relay: UL60730 1.5 Hp (10FLA - 60LRA) max 240Va
1 Fans relay: 5(2)A max 250Va
Mechanical Characteristics
Casing: PC+ABS UL94 V-0 resin casing, polycarbonate window, thermoplastic resin keys
Dimensions: front panel 74x32 mm, depth 59 mm (without terminals)
Terminals: screw/disconnectable terminals for cables with a diameter of 2.5mm
2
Connectors: TTL for connection of Unicard / Copy Card
Humidity: Operating / Storage: 10…90 % RH (non-condensing)
Regulations
Electromagnetic compatibility: The device conforms to Directive 2004/108/EC
Safety: The device conforms to Directive 2006/95/EC
Food Safety: The device complies with standard EN13485 as follows:
- suitable for storage
- application: air
- climate range A
- measurement class 1 in the range from -25°C to 15°C
(exclusively using Eliwell NTC probes)
NOTE: The technical specifications given in this document regarding measurement (range, accuracy, resolution, etc.) refer to the
instrument and not to any accessories provided, such as the probes. This means, for example, that the error introduced by
the probe must be added to the typical error of the instrument.
ELECTRICAL CONNECTIONs
Attention! Make sure the machine is switched off before working on the electrical connections.
The instrument is equipped with screw or disconnectable terminal blocks for connecting electrical cables with a max. diameter of
2.5 mm
2
(one wire per terminal for power connections): for the terminal ratings, see the label on the instrument. Do not exceed the
maximum permissible current; in case of higher loads, use a suitably rated contactor. Make sure the power supply voltage complies
with that required by the instrument. Probes have no connection polarity and can be extended using a normal bipolar cable (note that
the extension of the probes influences the electromagnetic compatibility - EMC - of the instrument: take great care with the wiring).
Probe cables, power supply cables and the TTL serial cable should be routed separately from power cables.
