TECHNICAL DATA (EN 60730-2-9)
Classification: operation (not safety) device for incorporation
Mounting: panel mounting with 71x29 mm (+0.2/-0.1 mm) drilling template
Type of action: 1.B
Pollution class: 2
Material class: IIIa
Overvoltage category: II
Rated impulse voltage: 2500V
Temperature: Operating: –5 … +55 °C - Storage: –30 … +85 °C
Power supply:
• 12Va/c (±10%)
• 24 Va ±10%
• 12-24Va/12-36Vc ±10%
• 115Va ±10% 50/60 Hz
• 230 Va ±10% 50/60 Hz
Consumption:
• 1.5 VA max (model 12Va/c)
• 3 W max (models: 24Va, 12-24Va/12-36Vc, 115Va and 230Va)
Digital outputs (relay): refer to the label on the device
Fire resistance category: D
Software class: A
NOTE: check the power supply specified on the instrument label.
