PT100/Tcj-Tck MODELs
PT100:
ACCURACY:
0.5% for whole scale + 1 digit
0.2% from -150 to 300°C
RESOLUTION: 0.1°C (0.1°F) from -199.9°C up to 199.9°C; 1°C (1°F) beyond
TcJ:
ACCURACY: 0.4% for whole scale + 1 digit
RESOLUTION: 0.1°C (0.1°F) from -199.9°C up to 199.9°C; 1°C (1°F) beyond
Tck:
ACCURACY:
0.5% for whole scale + 1 digit
0.3% from -40 to 800°C
RESOLUTION: 0.1°C (0,1°F) from -199.9°C up to 199.9°C; 1°C (1°F) beyond
MOUNTING - DIMENSIONS
The device is designed for panel mounting. Drill a 29x71 mm hole and insert the instrument; secure it with the special brackets provided. Do not
install the instrument in damp and/or dirty places; in fact, it is suitable for use in places with ordinary or normal levels of pollution.
Keep the area around the instrument cooling slots adequately ventilated.
74 mm
32 mm
29 mm
71 mm
70 mm
