- 6 -
TER-9
15 16 18 25 26 28
A1 A2 T1 T1 T2 T2
PRG +
MAN
_
MAN 2
ESC
OK
RESET
Auto
Supply voltage terminal (A1)(A2)
Display with back-light
Place for seal
Control buttons
Output - channel 2 (25-26-28)
Output - channel 1 (15-16-18)
Description
Terminals -sensor 1
Terminals -sensor 2
Plug-in module for replacing backup battery
