Ellard DC2 - Safety Edge and Photocell Connections; 8.2 k Resistive Safety Edge; Optical Safety Edge; Pneumatic Safety Edge

1 2 3 4 5 6
DIPON
DIP1
CT
GNDNC
Ph oto
beam
X5
X6X7
RC
Photocell (reflective)
Brown
Blue
White
Black
24V
1 2 3 4 5 6
DIPON
DIP1
CT
GND SKS 12V
Sa fet y edge
X5
X6X7
RC
8.2k Resistive Safety Edge
1 2 3 4 5 6
DIPON
DIP1
CT
GND SKS 12V
Sa fet y edge
X5
X6X7
RC
Optical Safety Edge
Brown
Green
White
Transmitter Receiver
Brown
White
8.2k
Note: Wire colour may vary
Note: Wire colour may vary
Remove factory fitted resistor
and connect safety edge
DIP Switch 1 (prog I) = ON
Remove factory fitted link and
connect Photocell
(N/C contact)
DIP Switch 6 (prog I) = OFF
Remove factory fitted resistor and
connect safety edge
DIP Switch 1 (prog I) = OFF
1 2 3 4 5 6
DIPON
DIP1
CT
GND SKS 12V
Sa fe ty edge
X5
X6X7
RC
Pneumatic Safety Edge
N/C Air Switch
Remove factory fitted resistor and
connect in series with Air Switch
DIP Switch 1 (prog I) = ON
8.2k Res
DIP3
Prog II Prog I
DIP3
Prog II Prog I
DIP3
Prog II Prog I
DIP3
Prog II Prog I
1 2 3 4 5 6
DIPON
1 2 3 4 5 6
DIPON
1 2 3 4 5 6
DIPON
1 2 3 4 5 6
DIPON
7
