Elma Elmasteam 4.5 basic HP - Technical Data

Product description
10
BA_Elmasteam 4
5
_EN_Vers. 01.2019 © Elma Schmidbauer GmbH
3.4 Technical Data
Elmasteam 4
5
basic
basic HP
Elmasteam 4
5
basic P-HP
Mains voltage (V) 220-240 | 115 - 120 220-240
Mains frequency (Hz) 50 / 60 50 / 60
Max. power consumption (W)
220 – 240 V
2800 2850
Max. power consumption (W)
115 – 120 V
1650 -
Rated power at 230 V (W) 2130 2180
Rated power at 115 V (W) 1540
Pressure tank volume (litres) 4 4
Max. filling volume (litres) 3,3 3.3
Operating pressure (bar) 4,5 4.5
Steam temperature at the
output of the nozzle (°C)
≤ 155 ≤ 155
Min. water connection pressure
(bar)
- 1.6
Max. water connection
pressure (bar)
- 6
Dimensions with hand piece
W x D x H (mm)
290 x 320 x 420 290 x 320 x 420
Dimensions with fixed nozzle
W x D x H (mm)
250 x 320 x 420 -
Weight (kg) 6,75 8.05
Case material PC/ABS PC/ABS
