3.7 Description of LED operation indicators
Fig. 3.7.1. View of front side
Pressure tank empty LED indicator (red)
Heater active (heat / reheat) LED indicator (orange)
Operating pressure reached (indicator can extinguish during
operation) LED indicator (green)
3.8 Safety valve
Fig. 3.8.1 safety valve (A)
See chapt. 7.7.
A
B
C
A
B
C
A
