Fig. 3.6.2.2. Elmasteam 4
5
basic HP rear side
Device connector with mains cable
Foot switch connector
Ball valve with plastic contact protection and mounted service hose
(chapter 7.2).
Fig. 3.6.2.3. Elmasteam 4
5
basic P-HP
Permanent water connection
