7. Close ball valve (Fig. 7.2.1.3).
8. Remove maintenance hose.
9. For machines that are operated with a pump in combination
with deionised water: Fill 1 level teaspoon of salt into the
pressure tank after the rinsing (see chapter 5.1).
*If no water flows away despite opened ball valve, this is possibly
closed by lime residues:
Remove maintenance hose and clear the opening in the ball valve
using a thin object.
Fig. 7.2.1.1 Connect water hose to the ball valve
Fig. 7.2.1.2 Ball valve opened
Fig. 7.2.1.3 Ball valve closed
