ELNA 654 - SECTION II Machine Set-up

Insert antenna into spool pin base. Pull
the antenna pole to its highest position
and turn slightly to align.
Remove the spool holders and place
the foam pads. The foam pads help
stabilize the thread spools.
Both domestic and industrial type
thread spools can be used.
Industrial type spools
Use the spool holders. Make sure that
the spools touch the bottom.
Domestic type spools
Remove spool holders and use spool
caps.
Positioning the Antenna
and Foam Pads
SECTION II
Machine Set-up
1
2
Decorative type spools (Specialty
threads)
Remove spool holders and place spool
directly on the foam pad to prevent the
thread from slipping underneath the
spool.
3
1
2
3
14
