ELNA 654 - Program Reference Cards

2
3
4
2
3
4
2
3
4
2
3
4
Program Reference Cards
NOTE: The program reference cards show
standard tension settings that may require
adjustment depending on the type of thread
or fabric.
Raise the cover to expose the program
reference cards. Select the program
reference card for the stitch you wish to
sew.
1. Program reference card
2. Stitch name
3. Differential feed
4. Stitch length
5. Cutting width
6. Blue tension setting
7. Red tension setting
8. Yellow tension setting
9. Green tension setting
10. Needle position
11. Instant rolled hem device/stitch width
finger lever
12. Movable cutting blade position
13. 2 thread converter
18
S
6
7
8
9
1
12
3
5
10
13
11
4
1
2
6
7
8
9
3
4
5
10
12
13
11
