ELNA 654 - Machine Parts

1
2
4
3
5
6
7
8
9
10
11
12
13
14
15
16
SECTION I
Machine Parts
1. Front cover
2. Stitch length display window
3. Flywheel (always turn towards you)
4. Power/light switch
5. Machine socket
6. Stitch length dial
7. Spool pin base
8. Foam pad
9. Spool holder
10. Spool pin
11. Antenna
12. Thread guides
13. Lower looper tension dial (green)
14. Upper looper tension dial (yellow)
15. Right needle (B) tension dial (red)
16. Left needle (A) tension dial (blue)
8
