Movable Cutting Blade Position
To Disengage Movable Cutting
Blade (down)
Open front cover. Push in
movable cutting blade release
and rotate blade down until it clicks
into position.
To Engage Movable Cutting
Blade (up)
Open front cover. Push in
movable cutting blade release
and rotate blade up.
1
Upper Looper and 2 Thread Converter
When using the upper looper, the
2 thread converter must be disengaged.
When not threading the upper looper,
the 2 thread converter must be engaged
into the upper looper eye.
To disengage the 2 thread converter,
lower the white handle on the converter.
To engage the 2 thread converter,
raise the white handle on the converter
to insert the tip into the eye of upper
looper.
1
2
2
1
2
24
1
2
