89
EC DECLARATION OF CONFORMITY
This machine complies with the following regulations:
EN 60335-1:2012;A11;A13;A1;A14;A2
EN 60335-2-28:2003;A1;A11
EN 62233:2008
EN 55014-1:2017;A11
EN 55014-2:2015
EN IEC 61000-3-2:2019
EN 61000-3-3:2013;A1
Supplier: Elna International Corp. SA
Address: Rue de Veyrot 14 - 1217 Meyrin - Switzerland
Problem Cause Reference
Seam puckering 1. The needle thread tension is too tight.
2. The needle thread is not threaded properly.
3. The needle is too heavy for the fabric being sewn.
4. The stitch length is too long for the fabric.
5. The foot pressure is not adjusted properly.
6. A stabilizer is not used when sewing very ne fabrics.
Page 12
Page 21
Page 17
Make stitch shorter.
Page 11
Apply a stabilizer.
The fabric is not
feeding smoothly
1. The feed dog is packed with lint.
2. The stitches are too ne.
3. The feed dog is not raised after ”drop feed” sewing.
Page 85
Make stitch longer.
Page 11
Loops on the
seams
1. The needle thread tension is too loose.
2. The needle is too thick or too ne for the fabric.
Page 12
Page 17
The machine does
not work
1. The machine is not plugged in or foot control is not connected.
2. Thread has been caught in the hook race.
3. The presser foot is not lowered.
Page 6
Page 85
Page 10
Buttonhole sewing
is not sewn
properly
1. The stitch density is not suitable for the fabric being sewn.
2. The interfacing has not been used for the stretch or synthetic fabric.
3. The buttonhole lever is not lowered.
Page 49
Apply an interfacing.
Page 47
The machine is
noisy
1. Thread has been caught in the hook race.
2. Lint has built up in the hook race or bobbin holder.
Page 85
Page 85
Layers shift 1. The foot pressure is not suitable for fabrics being sewn. Page 11
Auto thread
cutting failed
1. Thread is too thick for the auto thread cutting.
2. Threads have been caught in the thread cutter mechanism.
Page 7
Page 85
The stitch pattern
cannot be
selected.
1. The
straight stitch needle plate is attached to the machine.
2. The stitch pattern is 39 or 41 in
MODE 2 (Bridge stitches).
Page 33
Page 76
The needle thread
appears on the
wrong side of the
fabric when the
stitch width value
is larger than
“7.0”.
1. Thread tension is not balanced. Page 12
It is not abnormal for a faint humming sound to be heard from the internal motors.
The LCD screen and function key area may become warm after several hours of continuous use.
